IMS ROBOTICS MICRO light - Replacing the Way-Valve 3 (Cutter Air)

39
5.4.2.2 Replacing the way-valve 3 (cutter air)
Unreel the package from the drum. Unscrew the way-valve. Disconnect the two 10 mm
transparent hoses and unscrew the plug. Replace the directional valve. Reconnect the hoses
and plug. Fasten directional valve again with two screws.
Fastening screws Transparent hose
Screw, electrical connection
