IMS ROBOTICS MICRO light - Replacing the Camera

40
5.5 Replacing the camera
Unscrew the camera (Allen screws M4x10) and remove it carefully.
The cleaning ring (camera) for the air and water supply remains on the unit and is not sent
back.
Replace the camera. Do not operate the cutter drive without the camera! Screw on the
camera. Ensure correct seat of the O-ring!
Allen screws
M4x10
O-ring
