Manual de Instalação e Operação
3. PHYSICAL DESCRIPTION
This chapter presents the description of Smart Cap 485 in its physical characteristics
with all the components, as well as its functions.
3.1. FRONT PANEL
All the operation and monitoring of Smart Cap 485, can be made through its front panel
that presents 1 display of liquid crystal of 2 lines by 20 columns and 8 membrane keys. The
side illustration presents its front panel.
To change the screen press the wished key, to enable the second function press the key
“↓” followed by the wished function key.
SMART CAP 485 35
W
THD
V PFA
01 60 037 E
E
PO WE R FA CTOR CO N TROLLE R
SMART CAP 485
f4 f3
f0
V
W
THD
PFA
f1 f2
