Lighting & Electrical 99 Section 4
IMT 5005i / 6006i - Manual # 99904387
99904578-275A CONTACTOR
ITEM NO PART NO. DESCRIPTION KIT NO. QTY
1. 91722165 KIT-HRDW CONTACTOR REPLACEMENT 1
2. 60251278 PLATE-CONTACTOR MNT 1
3. 72063047 WASHER #10 LOCK 1 4
4. 72063239 WASHER # 8 LOCK 1 4
5. 72063268 WASHER #10 W FLAT ANSI B27.2Z 1 4
6. 72063271 WASHER # 8 W FLAT ANSI B27.2Z 1 4
7. 72602007 SCR-MACH #10-24X .62 BTNHD ZC 1 4
8. 72602011 SCR-MACH # 8-32X .62 BTNHD ZC 1 4
9. 77441336 SWITCH- 275A CONTACTOR 1
REV. B
1.
4004i), 6006i091001 (Model 6006i).
2. The 77441336 contactor is smaller than the 77441277. The mounting space for the 77441277 is 3.6” horizontally
by 4.9” vertically. The mounting space for the 77441336 is 3.4” square.
3. The 77441277 was mounted inside the mast, as shown. Use the replacement kit when mounting a
replacement 77441336 inside the mast where the 77441277 was located.
99904578-225A PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1 91722165 KIT-HRDW CONTACTOR REPLACEMENT 1
2 60251278 PLATE-CONTACTOR MNT 1
3 72063047 WASHER #10 LOCK 1 4
4 72063239 WASHER # 8 LOCK 1 4
5 72063268 WASHER #10 W FLAT ANSI B27.2Z 1 4
6 72063271 WASHER # 8 W FLAT ANSI B27.2Z 1 4
7 72602007 SCR-MACH #10-24X .62 BTNHD ZC 1 4
8 72602011 SCR-MACH # 8-32X .62 BTNHD ZC 1 4
10 77441534 SWITCH-225A CONTACTOR 12V OR 24V 1
REV. B
NOTES:
1. The 77441534 contactor is smaller than the 77441336. The mounting space for the77441336 is 3.4” square.
The mounting space for the 77441534 is 3.6” horizontally by 2.1” vertically.
2. The 77441336 was mounted inside the mast, as shown. Use the replacement kit when mounting a
replacement 77441534 inside the mast where the 77441336 was located.
