Parts 32 Section 4
IMT 5005i / 6006i - Manual # 99904387
MAST ASSEMBLY COMPLETE PARTS LIST (99904334)
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY
1. 51721422 KIT-HRDW BASE & MAST 5005I REF
2. 91722221 KIT- 5005I ELECTRICAL INSTALLATION REF
3. 51721707 KIT-HYD 5005I REF
4. 51721395 CYL-4.0/2.2 21.43S 33.52CC C 1
5. 52725224 WLDMT- BASE 5005I-6006I 1
6. 52722162 MAST WELDMENT-5005I/6006I 1
7. 60141134 PIN-TYPE NN 1.50X 9.25 1
8. 60132610 SHROUD- TURNTABLE GEAR 5005I 1
9. 60132385 SPACER- POWER UNIT 1
10. 70580194 CLAMP-I” CONDUIT HANGER W/BOLT 2
11. 71056632 GEAR-TRNTBL BRG 17.60” DIA 1
12. 60132856 BRKT-GREASE HOSE MNTG 4004I 1
13. 73051513 MOTOR-HYD 158-1083-001 1
14. 73734304 VALVE BANK-3 SEC SERIES 3GPM @ 500PSI 1
15. 60133635 CONTACT JUNCTION 1
16. 72062002 NUT .38-16 HEX 1 1
17. 76039295 GASKET-GEA19 008-10056-1 1
18. 70034382 CAP-GREASE PRO20 GC-RED 1 3
19. 72053301 COUPLING-GLV .12 SCH 40 1 1
20. 72053508 ZERK-NPT .12 1 1
21. 72060001 CAP SCR .25-20X .62 HH GR5 Z 1 5
22. 72060002 CAP SCR .25-20X .75 HH GR5 Z 1 7
23. 72060043 CAP SCR .38-16X .62 HH GR5 Z 1 1
24. 72060051 CAP SCR .38-16X 2.25 HH GR5 Z 1 2
25. 72060095 CAP SCR .50-13X 2.00 HH GR5 Z 1 1
26. 72060147 CAP SCR .62-11X 1.00 HH GR5 Z 1 2
27. 72060173 CAP SCR .62-11X 3.75 HH GR8 Z 1 18
28. 72060178 CAP SCR .62-11X 4.00 HH GR8 Z 1 15
29. 72062104 NUT .25-20 HEX NYLOCK 1 2
30. 72062207 NUT 8-32 HEX NYLOCK 1 4
31. 72063001 WASHER .25 FLAT 1 6
32. 72063049 WASHER .25 LOCK 1 10
33. 72063051 WASHER .38 LOCK 1 3
34. 72063053 WASHER .50 LOCK 1 3
35. 72063055 WASHER .62 LOCK 1 2
36. 72063119 WASHER .62 FLAT ASTM F436 1 31
37. 72063216 WASHER .62 N FLAT-CUT 3816 1 2
38. 72063242 WASHER .38 W FLAT ANSI B27.2 D 1 1
39. 72063271 WASHER # 8 W FLAT ANSI B27.2Z 1 4
40. 72602009 SCR-MACH # 8-32X 1.25 BTNHD SS 1 3
41. 72601941 SCR-MACH .25-20X .38 BTNHD ZC 1 1
42. 72602010 SCR-MACH # 8-32X 1.50 BTNHD SS 1 1
43. 72601949 CAP SCR .50-13X 1.25 SH ZC 1 2
44. 51721944 CABLE ASM- 1GA-3/8RNGX SWVL MX 60.00LG 2 1
