IMT 5005i Parts & Specifications

Parts 33 Section 4
IMT 5005i / 6006i - Manual # 99904387
45. 77441336 SWITCH- 275A CONTACTOR (SSC42-275) 1
46. 51722218 CABLE ASM- 1GA-3/8RNGX SWVL FX 13.50LG 2 1
47. 77441312 CABLE ASM-10GA-#10RNGX 1/4RNGX 6.00LG 2 1
48. 77441332 CABLE ASM- 1GA-1/4RNGX 3/8RNGX 46.50LG BLK 1
49. 51395121 HOSE-AA .13 X 13.50 (2-2) 100R17 3 1
50. 72060044 CAP SCR .38-16X .75 HH GR5 Z 1 1
51. 60132301 BRKT-VLV MNT 1
52. 73511282 POWER UNIT- 2.54CC 12VDC 1
53. 60141131 PLATE-ELEC ROTATOR BRKT BOTTOM 1
54. 60141130 PLATE- ELEC ROTATOR BRKT TOP 6006I 1
55. 71415015 KEEPER-PIN .50 1
WARNING:
1. Do not connect electrical power to crane until all connections have been tested. Sever injury could result.
2. Attach electrical wires and grounds to components before connecting to mast.
NOTES:
Apply black “Molub-Alloy 936 SF Heavy” gear grease to turntable gear.
WARNING
DO NOT CONNECT ELECTRICAL POWER
TO CRANE UNTIL ALL CONNECTIONS HAVE
BEEN TESTED. SEVER INJURY COULD
RESULT. ATTACH ELECTRICAL WIRES
AND GROUNDS TO COMPONENTS BEFORE
CONNECTING TO MAST.

IMT 5005i Specifications

General

Brand	IMT
Model	5005i
Category	Construction Equipment
Language	English
