iNetVu 1201 Flyaway - Page 21

iNetVu Troubleshooting Guide - 1201 Flyaway
Page 21 of 71
9) Open and remove Feed Arm from case.
10) Install Feed Arm onto EL Feed Arm Support plate and tighten retaining (2) nuts.
11) The BUC can be installed at this stage if not already installed. Follow the “Installing BUC with the
Universal Mounting Clamp kit” for mounting the BUC onto the mounting plate of the feed arm.
