iNetVu Troubleshooting Guide - 1201 Flyaway
Page 22 of 71
12) Connect internal PL Motor, PL Tilt Sensor and RX/TX cables (coming from Feed arm) ensure to
align groves marked by the white dash.
13) Open Reflector case and remove External Motor and Sensor cable.
Motor/Sensor
Cable
