5.3 Program Device and Reset Chip
1. Connect the device to the host computer and select it in the Probe/Kit drop-down.
2. Select the programming file as described in the Load Programming File section.
3. Connect to the device (see Connect Device).
4. Select the Reset Chip check box under Program Settings.
5. Click the Program button.
CYP programs the device and displays various messages in the Log. Then, a message in the Status Bar indicates
that the device was programmed successfully or that an error occurred.
The target device is reset and running.
