InfiRay Outdoor • Z oom V 2 • User Manual www.infirayoutdoor.com
All rights reserved and shall not be copied and distributed in any form without written permission
16 PIP Function
Picture-in-Picture (PIP) provides a floating window independent of the full
screen. This window shows part of the image which is enlarged to 2× in a
certain area centered on the reticle of the main image.
On the home screen, press and hold the U p butto n (6) to turn the PIP
function on/off.
When you press the U p b utton (6) to enlarge the main image, the
image in the PIP window will
also be enlarged by 2 times
accordingly. For example, if the
main image is enlarged by 1×,
2×, 3×, or 4×, the image in the
PIP window will be enlarged by
2×, 4×, 6×, or 8×respectively.
17 Stadiametric Rangefinder
In the home screen, press and hold the U p (6) + M (7) buttons at the
same time to turn the stadiametric ranging function on/off.
After this function is enabled, two horizontal lines used for measuring
will appear on the screen, and icons of three pre-configured objects
and measured values will be displayed on the right side.
Dimensions of three
pre-defined objects are:
- Deer: 1.7 m high
- Wild boar: 0.9 m high
- Hare: 0.2 m high
Adjust the target to the center of
the screen and align the horizontal lines with the target through long or
short pressing the U p (6) / D ow n (8) button.
The icon on the left shows the approximate distance of the
corresponding target.
Long press the M (7) button to exit to the stadiametric ranging function.
18 Hotspot Tracking
Zoom V2 series provides hotspot
tracking function, which allows you
to track the hottest object in the
image.
In the home screen, press and
hold the M (7) +D ow n (8 )
buttons at the same time to turn
To Next Page
