InFocus INF6502WB User Manual

DRAFT
Page 24
Save the whiteboard canvas
1) Tap More.
2) Tap Save.
3) Type a file name in the Name text box.
4) Select the file type:
File Type Option Choose this file type if you want to...
DigiEasel saves the whiteboard file for future editing.
JPG creates an image file. Note: The image file cannot be saved on the monitor and cannot
be re-opened by the monitor for later use. You will be prompted to save this file type
on a USB thumb drive.
PDF creates a printable document for others to view. Note: The PDF file cannot be saved
on the monitor and cannot be re-opened by the monitor for later use. You will be
prompted to save this file type on a USB thumb drive.
5) For JPG and PDF file types, tap Current view to save the visible portion of the canvas or tap Whole view to save
the entire canvas. Note: Whole view creates multiple pages and requires extra time to complete.
6) Enter the desired file location or accept the default location.
7) Tap Save.

InFocus INF6502WB Specifications

General

Panel life	- h
Pixel pitch	0.744 x 0.744 mm
Screen shape	Flat
Response time	6.5 ms
Backlight type	W-LED
Display diagonal	65 \
Touch technology	Multi-touch
Display brightness	350 cd/m²
Display technology	LED
LED backlighting type	Direct-LED
Supported video modes	1080p
Touchscreen technology	Capacitive
Contrast ratio (typical)	5000:1
Display number of colors	-
Viewing angle, horizontal	176 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
Number of simultaneous touchpoints	16
USB connector type	USB Type-A, USB Type-B
USB ports quantity	6
HDMI ports quantity	4
VGA (D-Sub) input ports	1
USB 2.0 Type-A ports quantity	5
Picture-in-Picture	No
Product color	Black
Panel mounting interface	400 x 400 mm
RMS rated power	20 W
Number of built-in speakers	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, USB, VGA

Weight and Dimensions

Depth	83.1 mm
Width	1520.5 mm
Height	895 mm
Weight	53500 g
