1.3.3.16 Cable Protection
A cable sealing sleeve is provided with iUI120 unit to protect the top of product
against water runoff.
Connect the cables, and snap in the part on the rear cover to cover the cables.
This sleeve also holds the antenna tool for GPRS and BT options.
Proposed position for cables:
Cable sealing sleeve clipped
on back cover
