Ingenico Link/2500 - Page 7

Page 7
Link
/
25
00 User Guide
Copyright© 2019 Ingenico
Opening the back cover
Switch off the terminal before opening the back cover
Turn the terminal over and unclip the back
cover by pushing on the clip as shown
with the arrows in the picture
Installing the battery
Remove the charging cable before exposing the battery
 Turn the terminal over and unclip the back
cover by pushing on the button as shown
above
 Take the battery pack included in the box
 Locate the battery pack connector beside
the battery compartment
 Plug the battery pack into the battery pack
connector
 Verify that it locks
 Place the battery pack in its compartment.
 Close the back cover
