6
Version 2.02 December-2002
2. The LED Terminal
2 or 3 Short Beeps: A User, Master or Installer function was successful.
1 Long Beep: A User, Master or Installer function has been unsuccessful.
Continuous Short Beeps*: Entry Delay Timer, Exit Delay Timer or Auto-arm Warning.
*NOTE:
Single Area systems. Any Terminals in the system will beep in response to Exit delay, Entry delay
or Auto-arm warnings.
Multi-Area systems. Only Terminals associated with a particular Area will beep in response to that
Area’s warning functions. IMPORTANT NOTE: Multi-Area Terminals will beep on all Area warning
functions.
2.2 BEEPER INDICATIONS.
PANIC. Keys 1 & 3 pressed simultaneously.
FIRE. Keys 4 & 6 pressed simultaneously.
MEDICAL. Keys 7 & 9 pressed simultaneously.
AUTO-LOGOFF: The Terminal will automatically
logoff the operator if there is no keypad activity
detected for 30 seconds.
2.1 SPECIAL KEY FUNCTIONS
CLR -Logoff the Terminal. (Exit the current Mode
of operation)
ENTER -Selects the specified programming Address.
(After PIN Code and the Address number
have been entered)
-Saves the data entered in a programming
Address.
NEXT -Select a Master User operation (Enter PIN code, press <NEXT> then the Address number).
HOME -Used to Arm the system, or an individual Area, in Home Mode.
Master User:
-Clear the data already entered if you have made a mistake.
