Using the Scan Tool
VIEWING OEM ENHANCED DTCs
3140d 41
The scan tool will display a code only
if codes are present in the vehicle’s
computer memory. If no codes are
present, a “No OEM Enhanced DTC’s
are presently stored in the vehicle’s
computer” is displayed. Press the M
button to return to the Main Menu.
3. If more than one code was retrieved press the DTC/FF button, as
necessary, to display additional codes one at a time.
Whenever the Scroll function is used to view additional codes,
the scan tool’s communication link with the vehicle’s computer
disconnects. To re-establish communication, press the
POWER/LINK
button again.
4. When the last retrieved DTC has been displayed and the DTC/FF
button is pressed, the scan tool returns to the “Priority” Code.
To view additional enhanced DTCs, repeat steps 1 through 4, above.
To exit the enhanced mode, press the M button. The scan tool
returns to the Main Menu.
Ford/Mazda OEM Enhanced DTCs
Mazda Enhanced DTCs are available for Mazda-branded
Ford vehicles only.
When OEM Enhanced is chosen from the System Menu (and Ford is
selected when prompted), the Ford Enhanced menu displays. You may
view DTCs for either the “Continuous Memory Test”, “KOEO (Key On
Engine Off) Test” or “KOER (Key On Engine Running) Test.”
1. Use the UP
and DOWN buttons,
as necessary, to highlight the desired
option, then press the ENTER
button.
When choosing to view KOER
Test DTCs, start the vehicle’s
engine before making your
selection.
If the KOER Test was selected, and
the vehicle’s engine is not running,
an advisory message shows on the
scan tool’s display.
- Press the M button to return to the
Main Menu.
If the KOEO Test was selected, and
the vehicle’s engine is running, an
advisory message shows on the
scan tool’s display.
- Press the M button to return to the
Main Menu.
