Inovance MD300 Series - Group F1 Motor Parameters

Chapter 5 Function Parameter Table
-44-
Code Name Setup range
Minimum
unit
Factory
default
value
Cha-
nge
F0-14
AO output
selection
0: Running frequency
1: Setup frequency
2: Output current
3PULSE input (corresponding
setup)
4: AI1 (corresponding setup)
5: AI2 (corresponding setup)
1 0 ż
F0-15
Start mode
0: Direct start
1: Rotation speed tracking
restart
1 0 ×
F0-16 Stop mode
0: Deceleration to stop
1: Coast to stop
1 0 ż
Group F1 Motor Parameters
F1-00
Motor type
selection
0: Common asynchronous
motor
1: Variable frequency
asynchronous motor
Permanent magnetic
synchronous motor (reserved)
1 0 ×
F1-01 Rated power
0.1kW 1000.0kW
0.1
model
dependent
×
F1-02 Rated voltage
0V440V
1
380V
×
F1-03 Rated current
0.00A655.35A
0.01
model
dependent
×
F1-04 Rated frequency
0.00Hz maximum frequency
1
50.00Hz
×
F1-05
Rated Rotation
speed
0rpm 30,000rpm
1
1460rpm
×
F1-06 Stator resistance
0.001ȍ65.535ȍ
0.001ȍ
model
dependent
ż
F1-07 Rotor resistance
0.001ȍ65.535ȍ
0.001ȍ
model
dependent
ż
F1-08
Leakage inductive
reactance
0.01mH655.35mH
0.01 mH
model
dependent
ż
