MD320/MD320N User Manual Parameter Description
111
This parameter is used to set the functions of the multifunctional digital input terminals.
Setup
value
Function Description
0 No function
Even when there is signal input, the inverter still
has no action. The no operation function can be
set on the unused terminals so as to prevent error
action.
1 Forward rotation (FWD)
Control the forward rotation and reverse rotation
of the inverter via the external terminals.
2 Reverse rotation (REV)
3
Three-line mode running
control
This terminal is used to conrm that the inverter
running mode is three-line control modeFor
detailed description, please refer to F4-11 three-
line control mode function code.
4
Forward rotation Jog
(FJOG)
FJOG refers to Jog forward rotation, while RJOG
refers to Jog reverse rotation. For details regarding
frequency and Jog acceleration/deceleration time
during the Jog running, refer to F8-00, F8-01 and
F8-02 function codes.
5
Reverse rotation Jog
(RJOG)
F4-04
DI5 terminal function
selection
Factory default value 13 (MS speed 2)
F4-05
DI6 terminal function
selection
Factory default value 0
F4-06
DI7 terminal function
selection
Factory default value 0
F4-07
DI8 terminal function
selection
Factory default value 0
F4-08
DI9 terminal function
selection
Factory default value 0
F4-09
DI10 terminal function
selection
Factory default value 0
