Inovance MD320 Series User Manual

Product Information MD320/MD320N User Manual
18
Chapter 2 Product Information
2.1 Designation Rules
2.2 Nameplate
Inverter Series
S
Single Phase 220
Voltage Level
Motor Power 0.4 0.75 …… 11 15
Mark 0.4 0.7 …… 11 15
Adaptable Motor Power
Corresponding Relationship
T
Three Phase 380
MD320N T 0.7 G B
Null None
Brake Unit
B Including Brake Unit
G Gerneral Type
Model
P Fan Pump Type
Fig.2-1 Designation Rules
Fig.2-2 Nameplate
Caution: The MD320N series is an upgrade of the MD320 series in terms of external
appearance and structural design. Except for special notes on the MD320N, all the following
information is appropriate for the MD320N series of products.
MODEL： MD 320NT0.7G
POWER： 0 .75kW
OUTPUT： 3 PH AC0V 2.3A 0Hz～300Hz
Shenzhen Inovance Technology Co.,Ltd.
S/N:
Barcode
INPUT： 3 PH AC380V 3.4A 50Hz/60Hz
