Parameter Description MD320/MD320N User Manual
114
Attached Table 1 MS Speed Function Description
K
4
K
3
K
2
K
1
F r e q u e n c y
Setup
Corresponding Parameter
OFF OFF OFF OFF MS speed 0 FC-0
OFF OFF OFF ON MS speed 1 FC-01
OFF OFF ON OFF MS speed 2 FC-02
OFF OFF ON ON MS speed 3 FC-03
OFF ON OFF OFF MS speed 4 FC-04
OFF ON OFF ON MS speed 5 FC-05
OFF ON ON OFF MS speed 6 FC-06
OFF ON ON ON MS speed 7 FC-07
ON OFF OFF OFF MS speed 8 FC-08
ON OFF OFF ON MS speed 9 FC-09
ON OFF ON OFF MS speed 10 FC-10
ON OFF ON ON MS speed 11 FC-11
ON ON OFF OFF MS speed 12 FC-12
ON ON OFF ON MS speed 13 FC-13
ON ON ON OFF MS speed 14 FC-14
ON ON ON ON MS speed 15 FC-15
Setup
value
Function Description
25 Counter input The input terminal of counting pulse.
26 Counter reset Clear the counter status.
27 Length count input Input terminal of length counting.
28 Length reset Length clear
29 Torque control inactive The torque control of inverter is inactive.
30
PULSE (pulse) frequency
input (enabled only for DI5)
It is pulse input terminal.
31 Reserved
32 Brake command
This terminal is enabled, and the inverter directly
switches to the DC brake status.
33
External fault normally
closed input
After the external fault signal is sent to the
inverter, the inverter reports fault and stops.
