Product Information MD320/MD320N User Manual
22
Item Specications
Individualized
function
Peripherals self-
detection upon
power-on
It can conduct safety detections on the peripherals upon
power-on, including earth and short circuit detections.
Shared DC Bus
Function
It can realize the function that multiple inverters share the DC
bus.
QUICK key The user can freely dene short-cut menus.
MF.K Key
Programmable key: Select the command channel switching/
forward and reverse rotations/jog operation.
Textile swing
frequency
control
Multiple triangular-wave frequency control function
Length control Reference length control function
Timing control
Timing control function: Setting time range between 0h to
65535 h.
Run
Running
command
channel
Three types of channels: operation panel reference, control
terminal reference and serial communication port reference.
These channels can be switched in various modes.
Frequency
source
There are totally ten types of frequency sources, such as
digital reference, analog voltage reference, analog current
reference, pulse reference and serial port reference. These
frequency sources can be switched in various modes.
Auxiliary
frequency
source
There are ten types of auxiliary frequency sources. It can
implement micro tuning and synthesis of auxiliary frequency.
Input terminal
There are five digital input terminals, one of which can be
used as high-speed pulse input. (The number of digital input
terminals can be expanded to ten) It can be compatible with
active PNP or NPN input mode.
There are two analog input terminals, one of which can be
used only as voltage input, while the other can be used as
voltage or current input. (It can expand one voltage input
terminal)
Output terminal
There is one high-speed pulse output terminal (can be
selected as open collector mode), with square wave output
of 0kHz to 50kHz. It can output such physical parameters as
setting frequency and output frequency.
One digital output terminal (can be expanded to two)
One relay output terminal (can be expanded to two)
One analog output terminal (can be expanded to two), with
optional 0//4mA to 20mA or 0/2V to 10V. It can realize the
output of such physical parameters as setting frequency and
output frequency.
