6 Parameter Description
-
202
-
■
86: Door lock bypass
Door lock bypass input signal. After the signal is active, the system enters the inspec-
tion state.
■
88: Wire holder feedback signal input
The wire holder feedback signal input function code 88 is added for the MCB.
1) Under the automatic and inspection status, if the wire holder feedback signal is
invalid, E67 is reported and the elveator stops immediately and cannot be started.
Meanwhile, the UCMP fault detection is initiated. If unintended movement occurs,
E65 is reported, which will cover E67.
2) To clear E67, press the resetting button RES/STOP on the hand-held manipulator,
or set F-2 to 1 on the MCB keypad. If the wire holder feedback signal is valid for
one second or longer, E67 is also cleared. After E67 is cleared, if the wire holder
feedback signal is invalid again, E67 is reported.
Function
Code
Name Setting Range Default Unit Property
F5-25 CTB input type 0 to 511 320 -
★
For example, the input signal types of the CTB of an elevator are set as follows:
Bit Parameter Name Default Bit Parameter Name Default
Bit0 Door 1 light curtain 0 Bit8 Light-load signal (digital) 1
Bit1 Door 2 light curtain 0 Bit9 Up leveling signal 1
Bit2 Door 1 open limit 0 Bit10 Down leveling signal 1
Bit3 Door 2 open limit 0 Bit11
Door machine overheat
detection
0
Bit4 Door 1 close limit 0 Bit12 Door machine 1 safety edge 0
Bit5 Door 2 close limit 0 Bit13 Door machine 2 safety edge 0
Bit6 Full-load signal (digital) 1 Bit14 Reserved -
Bit7 Overload signal (digital) 0 Bit15 Reserved -
0: NC input 1: NO input
Function
Code
Name Setting Range Default Unit Property
F5-26 Y1 function selection
0 to 31
1 -
★
F5-27 Y2 function selection 2 -
★
F5-28 Y3 function selection 3 -
★
F5-29 Y4 function selection 4 -
★
F5-30 Y5 function selection 0 -
★
F5-31 Y6 function selection 0 -
★
These parameters are used to set signals output by relay output terminals Y1 to Y6.
