9.3 Elevator Lock Function
1 Function description (Default setting of the system. Certain actions can be
modi󶍾ed by setting the parameters)
Elevator lock
■
After responding to all car calls that have been registered, the elevator returns to
󶍿
■
󶍿
the door and stops automatic running.
■
After the door closes, the elevator closes the lamp and fan in the car, and cancels
hall call display.
2 Wiring
■
Input and setting
Generally, the elevator lock signal is input via the elevator lock switch on the HCB of
󶍿
input terminal X21 as an example) according to the preceding table.
Scheme 1. Elevator lock input from HCB
󶙽Elevator lock signal input from HCB
HCB
Terminal
Name
Function
Connection between
MCTC-PG and encoder
S1
CN1
JP1
JP2
JP3
JP4
UP
DOWN
MCTC-HCB-H
MCTC-HCB-H
JP1
Interface for the
elevator lock switch
Pins 2 and 3 are for
switch input.
1 2 3 4
Elevator
lock input
MCTC-HCB-R1
CN1
J1
UP DOWN ST XF
MCTC-HCB-R1
XF/ST
Interface for the
󶍾
and elevator lock
switches
Pins 1 and 2 are for
elevator lock input.
Pins 3 and 4 are for
󶍾
1 2 3 4
Fire
emergency
input
Elevator
lock input
