3 Peripheral Devices and Options
-
88
-
2 Selection of ELCB
The earth leakage current of the controller is larger than 3.5 mA, requiring grounding
protection.
The controller generates DC leakage current in protective conductor. In this case, a
time-delay B-type ELCB must be used.
When the ELCB malfunction occurs, you can:
■
Use an ELCB with higher rated action current or a time-delay ELCB.
■
Reduce the carrier frequency.
■
Shorten the length of the motor drive cables.
■
Install a current leakage suppression device.
■
Use Chint Electric and Schneider brands.
3.2.2 Selection Guide of AC Input Reactor
An AC input reactor is installed to eliminate the harmonic current on the input side. As
an optional device, the reactor can be installed externally to meet strict requirements
of an application environment for harmonics. The recommended AC input reactor
manufacturer and models are listed in the following table.
1 Recommended AC input reactor models
󶙽Recommended AC input reactor models
Controller Model Rated Input Current (A) AC Input Reactor Model (Inovance)
 󶏒 
NICE-L-C-4002 6.5 MD-ACL-7-3.5-4T-4%
NICE-L-C-4003 10.5 MD-ACL-10-2.8-4T-4%
NICE-L-C-4005 14.8 MD-ACL-15-1.9-4T-4%
NICE-L-C-4007 20.5 MD-ACL-20-1.4-4T-4%
NICE-L-C-4011 29.0 MD-ACL-30-0.93-4T-4%
NICE-L-C-4015 36.0 MD-ACL-40-0.7-4T-4%
NICE-L-C-4018
41.0 MD-ACL-50-0.56-4T-4%
NICE-L-C-4018F
NICE-L-C-4022
49.5 MD-ACL-50-0.56-4T-4%
NICE-L-C-4022F
NICE-L-C-4030
62.0 MD-ACL-60-0.24-4T-2%
NICE-L-C-4030F
NICE-L-C-4037
77.0 MD-ACL-90-0.16-4T-2%
NICE-L-C-4037F
NICE-L-C-4045
93.0 MD-ACL-120-0.12-4T-2%
NICE-L-C-4045F
NICE-L-C-4055
113.0 MD-ACL-150-0.095-4T-2%
NICE-L-C-4055F
