2 Installation and Wiring
-
47
-
2.1.6 Removing and Reattaching Front Cover
1 Removing and reattaching the terminal cover with plastic structure
Removing procedure
and press downward so that the cover is detached.
Push the cover in the arrow direction. Removal is
completed.
Reattaching procedure
Align the cover with the edges of the controller and
push in the arrow direction.
Clamp the cover. Reattaching is completed.
To Next Page
