6 Parameter Description
-
251
-
Function
Code
Name Setting Range Default Unit Property
Fd-11 Expansion board 1: X1 input
0: Reserved
NO input:
1: Fire emergency signal
2: Overload signal
3: Full-load signal
5: Door machine 1 light
curtain signal
6: Door machine 2 light
curtain signal
7: Brake travel switch
feedback
8: UPS valid signal
9: Elevator lock signal
10: Safety circuit signal 2
11: Synchronous motor
self-lock feedback
12: Door lock circuit 2
feedback
13: Door machine 1 safety
edge signal
14: Door machine 2 safety
edge signal
15: Motor overheat signal #
16: Earthquake signal
17: Back door forbidden #
18: Light-load signal #
19: Half-load signal #
switchover
22: Door 1 open
23: Door 2 open
24: Brake travel switch 2
feedback
25: External fault
27: Door 2 selection
28: Single/Double door
selection NO input NC
point + 32
0 -
★
Fd-12 Expansion board 1: X2 input 0 -
★
Fd-13 Expansion board 1: X3 input 0 -
★
Fd-14 Expansion board 1: X4 input 0 -
★
Fd-15 Expansion board 1: X5 input 0 -
★
Fd-16 Expansion board 1: X6 input 0 -
★
Fd-17 Expansion board 1: X7 input 0 -
★
Fd-18 Expansion board 1: X8 input 0 -
★
Fd-19 Expansion board 1: X9 input 0 -
★
Fd-20
Expansion board 1: X10
input
0 -
★
Fd-21 Expansion board 2: X1 input 0 -
★
Fd-22 Expansion board 2: X2 input 0 -
★
Fd-23 Expansion board 2: X3 input 0 -
★
Fd-24 Expansion board 2: X4 input 0 -
★
Fd-25 Expansion board 2: X5 input 0 -
★
Fd-26 Expansion board 2: X6 input 0 -
★
Fd-27 Expansion board 2: X7 input 0 -
★
Fd-28 Expansion board 2: X8 input 0 -
★
Fd-29 Expansion board 2: X9 input 0 -
★
Fd-30
Expansion board 2: X10
input
0 -
★
These parameters are used to set the functions of input terminal X on the expansion
card. The NICE3000
new
system supports up to two expansion cards that are used to
expand the input terminal functions in the control cabinet or on the car.
