Inovance Monarch NICE-L-C-4037F

9 Description of Functions and Schemes
-
300
-
2 Wiring
1) 󶍿󶍾
Scheme 1. Fire emergency input from HCB
󶙽Fire emergency signal input from HCB
HCB
Terminal
Name
Function Terminal Wiring Description
S1
CN1
JP1
JP2
JP3
JP4
UP
DOWN
MCTC-HCB-H
MCTC-HCB-H
JP2
󶍾
emergency switch
Pins 2 and 3 are for
switch input.
1 2 3 4
Fire
emergency
input
MCTC-HCB-R1
CN1
J1
UP DOWN ST XF
MCTC-HCB-R1
XF/ST
Interface for the
󶍾
and elevator lock
switches
Pins 1 and 2 are for
elevator lock input.
Pins 3 and 4 are
󶍾
input.
1 2 3 4
Fire
emergency
input
Elevator
lock input
