9 Description of Functions and Schemes
-
318
-
3 Parameters
Function
Code
Name Setting Range
F-8 Test function 7: Entering the UCMP test with the keypad
F3-24
Program function
selection
0: Reserved
1: Slip experiment function enabled
2: UCMP manual test
Function
Code
Name Parameter Setting
F5-01 X1 function selection
01/33: Up leveling signal NO/NC (MCTC-SCB-A/A1)
01: Up leveling signal NO (MCTC-SCB-D)
F5-03 X3 function selection
02/34: Down leveling signal NO/NC (MCTC-SCB-A/A1)
02: Down leveling signal NO (MCTC-SCB-D)
F5-02 X2 function selection 03: Door zone signal NO
F5-08 X8 function selection 22: Shorting door lock circuit contactor feedback NO
F5-30 Y5 function selection 03: Shorting door lock circuit contactor control
Test method:
1) In inspection state, in the case of door lock closed, and in the door zone.
2) Set F-8 to 7 (or F3-24 to 2 using the keypad, and the system displays E88 and en-
ters the UCMP test function. At this moment, the door lock circuit is open.
3) Manually press and hold down the inspection button and the up or down button,
and the shorting motor stator contactor performs outputting and the door lock is
shorted. At this moment, the elevator performs inspection running.
4) After the elevator is divorced from the door zone (the door zone signal is invalid),
the hardware UCMP module will cancel door lock shorting. At this moment, the
elevator reports E65 (UCMP fault) and stops running.
◆
It is invalid to set F-8 to 7 and F3-24 to 2 in non-inspection state or door zone
or in the case of door lock inoperative.
◆
After F-8 is set to 7 or F3-24 is set to 2, clearing is automatically performed
after one running and after power failure.
◆
In UCMP test mode, the startup acceleration curve is linearly accelerated to
the inspection speed according to F3-08.
◆
and on.
◆
E65 can be manually reset only in inspection state.
