Item
Drive features
Control mode Vector control with a PG card
Startup torque Up to 200%, depending on the load
Speed control range 1:1000 (Vector control with a PG card)
Speed control
precision
±0.05% (Vector control with a PG card, 25 ± 10
ºC
）
Torque limit 200% of the rated torque
Torque precision ±5%
Frequency control
range
0 to 99 Hz
Frequency precision ±0.1%
Set resolution of
frequency
0.01 Hz/99 Hz
Output frequency
resolution
(Calculated resolution)
0.01Hz
No-load startup
compensation
In the event that the elevator load size is unknown, an
appropriate torque is applied to the motor according
to the elevator running direction, achieving smooth
startup, minimizing jerk at the moment of startup and
improving the riding comfort.
Braking torque 150% (External braking resistor), built-in braking unit
Acceleration/
Deceleration time
0.1 to 8s
Carrier frequency 2 to 16kHz
Battery running
Upon power failure, the elevator performs leveling at
from the battery.
PG interface
Type of PG card
endat absolute value types
Frequency dividing
output of PG card
signal
OA orthogonal to OB
I/O signal
Optocoupler input
control power supply
Isolation 24 VDC
Low voltage
optocoupler isolation
input
24 x DI. Optocoupler control signals are isolation 24
VDC power input signals.
High voltage
optocoupler isolation
input
3 x DI
Relay output
6 normally open contacts, single-pole single-throw, 5 A
contact switchover capability, contact load (Resistive):
5A250VAC or 5A28VDC
USB interface Commissioning by cell phone
CAN communication
port
2 communication ports (Car top communication,
parallel or group control)
MOD communication
2 communication ports (Outbound communication,
residential area monitoring or Internet of Things)
Analog input port
range -10 V to +10 V, precision 0.1%
