Inovance Monarch NICE-L-C-4037F

9 Description of Functions and Schemes
-
325
-
2 Parameters
The parameter setting related to emergency evacuation by controller drive is
described in the following table.
Function
Code
Value Description Remarks
F8-10 1: UPS
Emergency
evacuation operation
mode at power
failure
-
F5-20 (X20) 59
Emergency
evacuation signal NC
Assume that X20 is used as the NC input of
emergency evacuation signal
F5-31 (Y6) 13
Emergency
evacuation
automatic
switchover
Only Y6 can be used for emergency
evacuation output.
The parameter setting related to emergency evacuation by shorting stator braking is
described in the following table.
Function
Code
Value Description Remarks
F8-10
0: Motor
not
running
Emergency evacuation
operation mode at
power failure
-
F5-20 (X20) 59
Emergency evacuation
signal NC
Assume that X20 is used as the NC
input of emergency evacuation signal
F5-31 (Y6) 13
Emergency evacuation
automatic switchover
Only Y6 can be used for emergency
evacuation output.
F6-45 Bit15 = 1 Enabled -
The UPS capacity recommended for the power rating is listed in the following table.
󶙽The UPS capacity recommended for the power rating is listed in the following table.
UPS Power Controller Power
 󶙮
2kVA (1400W-1600W) 󶙮
3kVA (2100W-2400W) 󶙮󶙮
