Inovance Monarch NICE-L-C-4037F

9 Description of Functions and Schemes
-
327
-
2 Parameters
The parameter setting related to emergency evacuation by controller drive is
described in the following table.
Function
Code
Value Description Remarks
F8-10 1: UPS
Emergency evacuation
operation mode at power
failure
-
F5-20 (X20) 27
Emergency evacuation
signal NO
Assume that X20 is used as the NO
input of emergency evacuation
signal.
F5-31 23
Emergency evacuation
completed
It is used to notify that ARD
emergency evacuation is completed.
The parameter setting related to emergency evacuation by shorting stator braking is
described in the following table.
Function
Code
Value Description Remarks
F8-10
0: Motor not
running
Emergency evacuation
operation mode at
power failure
-
F5-20 (X20) 27
Emergency evacuation
signal NO
Assume that X20 is used as the NO
input of emergency evacuation
signal.
F5-31 23
Emergency evacuation
completed
It is used to notify that ARD
emergency evacuation is completed.
NOTE
Pay attentions to the following precautions:
◆
Select the ARD with the nominal output power equal to or larger than the
motor rated power.
◆
For the 380 V elevator ARD, only two phases are used for emergency evacua-
tion output, and you need to ensure that wiring to the controller is correct;
the output is single-phase 380 V, and you need to ensure that the transform-
er meets the requirements on the input side.
◆
If CAN communication is used, F5-20/F5-31 needs not be set for ARD emer-
gency evacuation.
Other parameters related to emergency evacuation
Function
Code
Value Description
F3-22 
2
Acceleration rate at emergency evacuation
F6-48  Emergency evacuation switching speed
F6-49 0 to F6-00 󶍿
F8-09 0.05m/s
Emergency evacuation operation speed at power
failure
