9 Description of Functions and Schemes
-
335
-
HCB addresses of front door: 1 to 15
HCB+16 addresses of back door: 17 to 31
3 Parameters
Type
Door Control
Mode
Parameter Setting
Service
Floor
Operation
Box CCB
Wiring
HCB
Address
Setting
Mode
Selection
Other
Parameters
Mode 1
Simultaneous
control
FC-04 = 0
FB-00 = 2 (CTB
analog input)
FE-33 Bit15 = 1
15
The CCB of
front door is
connected
to CN7 on
the CTB.
The CCB of
back door is
connected
to CN8 on
the CTB.
HCB
address
of front
door:
HCB
address
of back
door:
Mode 2
Hall call
independent,
car call
simultaneous
FC-04 = 1 Same as mode 1 15
Mode 3
Hall call
independent,
car call
manual
control
FC-04 = 2 (CTB
analog input)
F6-40 Bit4 = 1
Same as mode 1 15
Mode 4
Hall call
independent,
car call
independent
FC-04 = 3 Same as mode 1 15
The CCB of
front door is
connected
to CN7 on
the CTB.
The CCB of
back door is
connected
to the CCB
of front door
in cascade.
In mode 3, the car door to open is controlled as follows:
◆
The control switch is connected to JP16 on the CCB. When JP16 is ON, only the front door
opens; when JP16 is OFF, only the back door opens.
