2 Installation and Wiring
-
80
-
Function
Code
Name Setting Range Value
F5-26 Y1 function selection
1: RUN contactor
2: Brake contactor
3: Shorting door lock circuit contactor
Others:
0: Invalid
5: Door machine 1 open
6: Door machine 1 close
7: Door machine 2 open
8: Door machine 2 close
9: Brake and RUN contactors healthy
10: Fault status
11: Operation status
12: Shorting motor stator contactor
13: Evacuation automatic switchover
14: Normal state of integration
15: Evacuation buzz
16: Brake strong shock
17: Up signal
18: Fan operation
19: Medical sterilization control
20: Non-door zone stop output
21: Electric lock control
22: Non-service state
23: Emergency evacuation completed
25: Wire holder reset
26: Braking pipe short circuit output
1
F5-27 Y2 function selection 2
F5-28 Y3 function selection 3
F5-29 Y4 function selection 4
F5-30 Y5 function selection 0
F5-31 Y6 function selection 0
