3 Peripheral Devices and Options
-
91
-
Physical dimensions of 60 A AC input reactor
A
B
C
D
E
F
G
H
I
J
K
L
R
S
T
X
Y
Z
󶙽Physical dimension diagram of 60 A AC input reactor
󶙽Physical dimensions of 60 A AC input reactor
Rated
Current
(A)
A
(mm)
B
(mm)
C
(mm)
D
(mm)
E
(mm)
F (mm)
G
(mm)
H
(mm)
I
(mm)
J
(mm)
K
(mm)
L
(mm)
60 64 160 195 80 ± 10 75 ± 5 35 ± 5 135 120 ± 1 92 ± 2  72 ± 2 
