3 Peripheral Devices and Options
-
98
-



The following two formulas can be obtained:
K × Pr = Pb × D = U × U/R × D
Pr = (U × U × D)/(R × K)
The regen. resistor power is calculated accordingly.
󶎀
resistor does not get overheated. The K value can be increased appropriately on the
condition of good dissipation and should not exceed 50%. Failure to comply may re-
󶍾
Braking frequency (D) is determined by application. Typical values of braking frequen-
󶍽
󶙽󶍽
Application Elevator
Winding and
unwinding
Centrifuge
Occasional
braking load
General
application
Braking
Frequency
20% to
30%
20% to 30% 50% to 60% 5% 10%
■
Selection guide of regen. resistor
󶙽Selection of braking components of the NICE3000
new
Controller Model
Power of
Applicable
Motor (kW)
Max.
Resistance
of Regen.

Min.
Resistance
of Regen.

Power
(W)
Braking Unit
 󶏒 
NICE-L-C-2002 1.1 145.0 125.0 300
Built-in
NICE-L-C-2003 1.5 105.0 90.0 450
220-NICE-L-C-4007 2.2 72.0 63.0 600
220-NICE-L-C-4011 3.7 43.0 37.0 1100
220-NICE-L-C-4015 4.0 40.0 35.0 1200
220-NICE-L-C-4018
5.5 29.0 25.0 1600
220-NICE-L-C-4018F
220-NICE-L-C-4022
11.0 18.0 16.0 3500
Built-in
220-NICE-L-C-4022F
220-NICE-L-C-4030
15.0 13.0 13.0 4500
220-NICE-L-C-4030F
