At a Glance
Button Icons
Icon What it does
Gauge Screens - Enters Main Menu
Menus - Brings you back to the home screen
Gauge Screens -HighlightsPIDlocations
Menus - Selects menu options & closes text boxes
Home
Enter
Down
Gauge Screens - PID location navigation
Menus - Scrolling up
Up
Common Terms
PID - Parameter IDs
Term What it is
Data taken from a vehicle & viewed in a gauge
DPF - Diesel Particulate Filter Requiredonnewdieselstolteroutsoot
EAS - Expandable Accessory
System
Allows you to connect aftermarket sensors and
other devices such as turbo timers
ECM - Engine Control
Module
(aka ECU) A computer that controls various
sensors and engine components
TCM - Transmission Control
Module
(aka TCU) A computer that controls automatic
transmissions
PCM - Power Control
Module
(aka PCU) Combines and provides power for
the ECM and TCM
Left
Right
Gauge Screens - PID location navigation
Menus - Scrolling down
Gauge Screens - PID location navigation
Menus - Back to previous menu or option
Gauge Screens - PID location navigation
Menus - Brings you to next menu
