Integra DHC-80.1 User Manual

100
Advanced Setup—Continued
Level Calibration
Level Calibration can be set automatically by Audyssey MultEQ
®
XT Room Correction and Speaker Setup (see
page 54).
If you prefer, you can adjust the level of each speaker with the built-in test tone so that the volume of each speaker is
the same at the listening position.
Left, Front Wide Left, Front High Left, Center, Front High Right, Front Wide Right, Right, Surr Right,
Surr Back Right, Surr Back Left, Surr Left, Subwoofer 1, Subwoofer 2
*1
The levels can be adjusted from –12.0 to +12.0 dB in 0.5 dB steps (–15.0 to +12.0 dB for the subwoofer).
Notes:
• The speakers cannot be calibrated while the output of the AV controller is muted.
• The test tone is output at the standard level for THX, which is 0 dB (absolute volume setting 82). If you
normally listen at volume settings below this, be careful because the test tone will be much louder.
• You cannot get the test tone from speakers that you set to “No” or “None” in the “Speaker Configuration”
(see page 98).
*1 If the “Subwoofer” setting is set to “1ch”, this setting cannot be selected.
Tip:
If you’re using a handheld sound level meter, adjust the level of each speaker so that it reads 75 dB SPL at the listening
position, measured with C-weighting and slow reading.
Equalizer Settings
This setting is set automatically by Audyssey MultEQ
®
XT Room Correction and Speaker Setup (see page 54).
With the Equalizer settings, you can adjust the tone of speakers individually with a 15-band equalizer. The volume of
each speaker can be set on this page.
Notes:
• You can select: “25Hz”, “40Hz”, “63Hz”, “100Hz”, “160Hz”, “250Hz”, “400Hz”, “630Hz”, “1000Hz”, “1600Hz”,
“2500Hz”, “4000Hz”, “6300Hz”, “10000Hz” or “16000Hz”. And for the subwoofer, “25Hz”, “40Hz”, “63Hz”,
“100Hz”, or “160Hz”.
• While the Direct listening mode is selected, the equalizer settings have no effect.
Equalizer Manual: You can adjust the equalizer for each speaker manually. If you selected “Manual”,
continue with this procedure.
1
Press the Down [w] button to select “Channel”, and then use the
Left and Right [e]/[r] buttons to select a speaker.
2
Use the Up and Down [q]/[w] buttons to select a frequency, and
then use the Left and Right [e]/[r] buttons to adjust the level at
that frequency.
The volume at each frequency can be adjusted from –6 to +6 dB in 1 dB
steps.
Tip:
Low frequencies (e.g., 63Hz) affect bass sounds; high frequencies (e.g.,
16000Hz) affect treble sounds.
3
Use the Up [q] button to select “Channel”, and then use the Left
and Right [e]/[r] buttons to select another speaker.
Repeat steps 1 and 2 for each speaker.
You cannot select speakers that you set to “No” or “None” in the “Speaker
Configuration” (page 98).
Audyssey: The tone for each speaker is set automatically by Audyssey MultEQ
®
XT Room
Correction and Speaker Setup. Be sure to select this setting after having performed
Room Correction and Speaker Setup. “Audyssey” is automatically selected when
“Dynamic EQ” and “Dynamic Volume” are set to “On” (see page 104). When
“Audyssey” is selected, “Dolby Volume” becomes “Off” automatically
(see page 120).
Off: Tone off, response flat (default).
