12
Front & Rear Panels—Continued
A VCR/DVR IN/OUT
Here you can connect a VCR or DVR (digital video
recorder). Input and output jacks include S-Video,
composite video, and analog audio.
B DVD/BD IN
Here you can connect a DVD/BD player. Input
jacks include S-Video, composite video, and analog
audio. You can connect a DVD/BD player’s 2-chan-
nel analog audio output.
C MULTI CH input: FRONT L/R, CENTER,
SUBWOOFER, SURR L/R, and SURR BACK
L/R
This analog multichannel input is for connecting a
component with a 5.1/7.1-channel analog audio out-
put, such as a DVD player, DVD-Audio or Super
Audio CD-capable player, or an MPEG decoder.
D PRE OUT: FRONT L/R, CENTER, SURR L/R,
SURR BACK L/R, and FRONT HIGH/WIDE
L/R
These multichannel analog audio outputs can be
connected to the analog audio input on a multichan-
nel power amplifier.
PRE OUT: SW1, SW2
These analog audio outputs can be connected to a
powered subwoofer. You can connect the powered
subwoofer with each jacks respectively. Level and
distance can be set individually for each output.
E PRE OUT: ZONE 2, ZONE 3
These analog audio outputs can be connected to the
line inputs on amplifiers in Zone 2 and Zone 3. The
SW jacks can be connected to the inputs on pow-
ered subwoofers in Zone 2 and Zone 3.
F PRE OUT: FRONT L/R, CENTER,
SUBWOOFER 1/2, SURR L/R, SURR BACK
L/R, and FRONT HIGH/WIDE L/R
These balanced XLR outputs are for connecting a
multichannel power amplifier and powered sub-
woofer.
The FRONT L/R and SURR BACK L/R outputs can
be used with front speakers and surround back
speakers, respectively, or used to bi-amp the front
speakers. See “Bi-amping the Front Speakers” on
page 20.
G SIRIUS antenna (North American models)
This jack is for connecting a SIRIUS Satellite Radio
antenna, sold separately (see the separate SIRIUS
instructions).
See pages 17 to 40 for connection information.
To Next Page
