Troubleshooting—Continued
The following settings can be made for the S-
Video or composite video inputs
You must use the buttons on the AV controller to make
these settings.
1. While holding down the input selector button for the
input source that you want to set, press the [Setup]
button.
2. Use the Left and Right [e]/[r] buttons to change
the setting.
3. Press the input selector button for the input source
that you want to set when you’ve finished.
• Video Attenuation
This setting can be made for the DVD/BD, VCR/
DVR, CBL/SAT, Game or AUX1 input.
If you have a games console connected to the
S-Video and composite video input, and the picture
isn’t very clear, you can attenuate the gain.
Video ATT:OFF: (default).
Video ATT:ON: Gain is reduced by 2 dB.
The AV controller can upconvert component video, S-
Video, and composite video sources for display on a TV
connected to the HDMI outputs. However, if the picture
quality of the source is poor, upconversion may make the
picture worse or disappear altogether.
In this case, try the following:
1 If the video source is connected to a component
video input, connect your TV to the
COMPONENT VIDEO MONITOR OUT.
If the video source is connected to an S-Video input,
connect your TV to a MONITOR OUT S.
If the video source is connected to a composite video
input, connect your TV to the MONITOR OUT V.
2 On the main menu, select “1. Input/Output
Assign”, and then select “2. HDMI Input”.
Select the relevant input selector, and assign it to
“- - - - -” (page 47).
3 On the main menu, select “1. Input/Output
Assign”, and then select “3. Component Video
Input” (page 48).
If the video source is connected to COMPONENT
VIDEO IN1, select the relevant input selector, and
assign it to “IN1”.
If the video source is connected to COMPONENT
VIDEO IN2, select the relevant input selector, and
assign it to “IN2”.
If the video source is connected to COMPONENT
VIDEO IN3, select the relevant input selector, and
assign it to “IN3”.
If the video source is connected to an S-Video input
or composite video input, select the relevant input
selector, and assign it to “- - - - -”.
If “Monitor Out” setting is set to “Analog”, press [VCR/
DVR] and [Return] buttons on the AV controller at the
same time. Select “Skip” in the “VideoProcessor” setting
by pressing the [Return] button repeatedly on the dis-
play. To reset back to the original setting, press the same
button at the same time. If you select “Use”, the AV con-
troller will output video signals from the video proces-
sor.
The AV controller contains a microcomputer for signal
processing and control functions. In very rare situations,
severe interference, noise from an external source, or
static electricity may cause it to lockup. In the unlikely
event that this happens, unplug the power cord from the
wall outlet, wait at least five seconds, and then plug it
back in again.
Onkyo is not responsible for damages (such as CD
rental fees) due to unsuccessful recordings caused by
the unit’s malfunction. Before you record important
data, make sure that the material will be recorded cor-
rectly.
Before disconnecting the power cord from the wall out-
let, set the AV controller to Standby.
Important Note Regarding Video Playback
