11
Getting to Know the AV Receiver
—Continued
D
COMPONENT VIDEO IN 1, 2, and 3
These RCA component video inputs are for con-
necting components with component video outputs,
such as DVD players.
E
HDMI IN 1, 2, and OUT (DTR-7.6 only)
HDMI (High Definition Multimedia Interface) con-
nections carry digital audio and digital video.
The HDMI inputs are for connecting components
with HDMI outputs, such as DVD players.
The HDMI output is for connecting a TV or projec-
tor with an HDMI input.
F
COMPONENT VIDEO OUT
This RCA component video output is for connect-
ing a TV or projector with a component video input.
G
XM antenna (on North American model)
This jack is for connecting an XM digital antenna,
sold separately.
H
AM ANTENNA
These push terminals are for connecting an AM
antenna.
I
MONITOR OUT
The S-Video or composite video jack should be
connected to a video input on your TV or projector.
J
FM ANTENNA
This jack is for connecting an FM antenna.
K
12V TRIGGER OUT (A/B/C)
These outputs can be connected to the 12-volt trig-
ger inputs on other components.
L
IR IN A/B and OUT
A commercially available IR receiver can be con-
nected to the IR IN A or B jack, allowing you to
control the AV receiver while you’re in Zone 2, or
control it when it’s out of sight, for example,
installed in a cabinet.
A commercially available IR emitter can be con-
nected to the IR OUT jack to pass IR (infrared)
remote control signals along to other components.
M
ZONE 2 OUT L/R and SUBWOOFER
The L/R jacks can be connected to a line input on an
amplifier in Zone 2. The SUBWOOFER jack can be
connected to the input on a powered subwoofer in
Zone 2.
N
RS232
This port is for connecting the AV receiver to home
automation equipment and external controllers.
O
AC INLET
This connector is for connecting the supplied power
cord.
P
GND screw
This screw is for connecting a turntable’s ground
wire.
Q
PHONO IN
This analog audio input is for connecting a turnta-
ble.
R
CD IN
This analog audio input is for connecting a CD
player’s analog audio output.
S
TAPE IN/OUT
This analog audio input and output are for connect-
ing a recorder with an analog audio input and out-
put, such as a cassette deck, MD recorder, etc.
T
VIDEO 3 IN
A VCR for playback only, or a cable or satellite
receiver can be connected here. There’s S-Video and
composite video input jacks for connecting the
video signal.
U
VIDEO 1 IN/OUT and VIDEO 2 IN/OUT
One or two video components can be connected
here for recording and playback, such as a VCR.
There’s S-Video and composite video input and out-
put jacks for connecting the video signal.
V
DVD IN
This input are for connecting a DVD player. There’s
S-Video and composite video input jacks for con-
necting the video signal, and stereo (FRONT) and
multichannel 5.1/7.1 jacks for connecting the ana-
log audio signals.
W
ZONE 2 SPEAKERS
These terminal posts are for connecting speakers in
Zone 2.
X
PRE OUT FRONT L/R, SURROUND L/R,
CENTER, SUBWOOFER, and SURR BACK
L/R
This 5.1/7.1 analog audio output can be connected
to the analog audio input on another power ampli-
fier, for when you want to use the AV receiver as a
preamplifier. The SUBWOOFER jack is for con-
necting a powered subwoofer.
Y
FRONT, CENTER, SURROUND, and
SURROUND BACK SPEAKERS
These terminal posts are for connecting the front
L/R, center, surround L/R, and surround back L/R
speakers.
Z
AC OUTLETS
These switched AC outlets can be used to supply
power to other AV components. The type and num-
ber of outlets depends on the country in which you
purchased your AV receiver.
See pages 17–36 for hookup information.
