Specification
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
Specifications and features are subject to change without
notice.
Power Output
DTR-7.6:
2 channels driven: 105 W + 105 W (8 Ω , 20 Hz–20 kHz, FTC)
140 W + 140 W (6 Ω , 1 kHz, DIN)
170 W + 170 W (6
Ω , 1 kHz, JEITA)
DTR-6.6:
2 channels driven: 100 W + 100 W (8 Ω , 20 Hz–20 kHz, FTC)
130 W + 130 W (6 Ω , 1 kHz, DIN)
160 W + 160 W (6
Ω , 1 kHz, JEITA)
Dynamic Power
DTR-7.6: 240 W + 240 W (3 Ω , Front)
180 W + 180 W (4
Ω , Front)
125 W + 125 W (8
Ω , Front)
DTR-6.6: 230 W + 230 W (3 Ω , Front)
170 W + 170 W (4
Ω , Front)
115 W + 115 W (8
Ω , Front)
THD (Total Harmonic
Distortion) 0.08% (Power Rated)
Damping Factor 60 (Front, 1 kHz, 8
Ω )
Input Sensitivity and
Impedance 200 mV/ 47 k
Ω (LINE)
2.5 mV/47 k
Ω (PHONO MM)
Output Level and
Impedance 200 mV/ 470
Ω (REC OUT)
Phono Overload 70 mV (MM 1 kHz, 0.5%)
Frequency Response 5 Hz–100 kHz/ +1 dB-3 dB (LINE)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 106 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
Speaker Impedance 4
Ω – or 6 Ω –
Input Sensitivity/Output
Level and Impedance 1 Vp-p /75
Ω (Component and S-Video Y)
0.7 Vp-p /75
Ω (Component Pb/Cb,Pr/Cr)
0.28 Vp-p /75
Ω (S-Video C)
1 Vp-p /75
Ω (Composite)
Component Video
Frequency Response 5 Hz – 100 MHz
Tuning Frequency Range North American: 87.5 MHz– 107.9 MHz
Australian: 87.5 MHz– 108.0 MHz
Usable Sensitivity Stereo: 22.2 dBf (75
Ω IHF)
Mono: 15.2 dBf (75
Ω IHF)
Signal to Noise Ratio Stereo: 67 dB (IHF-A)
Mono: 73 dB (IHF-A)
THD Stereo: 0.5% (1 kHz)
Mono:0.3% (1 kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB
Stereo Separation 40 dB (1 kHz)
Tuning Frequency Range North American: 530 kHz–1710 kHz
Australian: 522/530 kHz–1611/1710 kHz
Usable Sensitivity 300 µV/m
Signal to Noise Ratio 40 dB
THD 0.70%
Power Supply North American: AC 120 V, 60 Hz
Australian: AC 230-240 V, 50 Hz
Power Consumption North American: 7.5 A
Australian: 680 W
Standby Power
Consumption North American: 0.1 W
Australian: 0.2 W
Dimensions
(W
× H × D) 435 × 173.5 × 428.5 mm
17-1/8" × 6-13/16" × 16-7/8"
Weight North American: 13.1 kg
28.9 lbs.
Australian: 13.3 kg
29.3 lbs.
HDMI DTR-7.6: IN1, IN2
Component IN1, IN2, IN3
S-Video DVD, VIDEO1, VIDEO2, VIDEO3,
VIDEO4
Composite DVD, VIDEO1, VIDEO2, VIDEO3,
VIDEO4
HDMI DTR-7.6: OUT
Component OUT
S-Video MONITOR OUT, VIDEO1, VIDEO2
Composite MONITOR OUT, VIDEO1, VIDEO2
Digital Inputs Optical: 5 (1 on Front Panel)
Coaxial: 2
Analog Inputs DVD (MULTICHANNEL), VIDEO1,
VIDEO2, VIDEO3, VIDEO4, TAPE, CD,
PHONO
Multichannel Input 7.1 ch (DVD)
Digital Output Optical: 1
Analog Outputs TAPE, VIDEO1, VIDEO2, ZONE2
L/R/SUBWOOFER
Multichannel Pre
Outputs 7.1 ch
Speaker Outputs L, R, C, SL, SR, SBL, SBR
ZONE2 (L, R)
Phones 1
RS232 1
IR Input/Output 2/1
12 V Trigger Out A, B, C
