Intel 8XC251SA User Manual

A-23
INSTRUCTION SET REFERENCE
Table A-26. Summary of Bit Instructions
Clear Bit CLR bit bit ← 0
Set Bit SETB bit bit ← 1
Complement Bit CPL bit bit← Øbit
AND Carry with Bit ANL CY,bit CY ← CY Λ bit
AND Carry with Complement of Bit ANL CY,/bit CY ← CY Λ Øbit
OR Carry with Bit ORL CY,bit CY ← CY V bit
ORL Carry with Complement of Bit ORL CY,/bit CY ← CY V Øbit
Move Bit to Carry MOV CY,bit CY ← bit
Move Bit from Carry MOV bit,CY bit ← CY
Mnemonic <src>,<dest> Notes
Binary Mode Source Mode
Bytes States Bytes States
CLR
CY Clear carry 1 1 1 1
bit51 Clear dir bit 2 2 (2) 2 2 (2)
bit Clear dir bit 4 4 3 3
SETB
CY Set carry 1 1 1 1
bit51 Set dir bit 2 2 (2) 2 2 (2)
bit Set dir bit 4 4 (2) 3 3 (2)
CPL
CY Complement carry 1 1 1 1
bit51 Complement dir bit 2 2 (2) 2 2 (2)
bit Complement dir bit 4 4 (2) 3 3 (2)
ANL
CY,bit51 AND dir bit to carry 2 1 (3) 2 1 (3)
CY,bit AND dir bit to carry 4 3 (3) 3 2 (3)
ANL/
CY,/bit51 AND complemented dir bit to carry 2 1 (3) 2 1 (3)
CY,/bit AND complemented dir bit to carry 4 3 (3) 3 2 (3)
ORL
CY,bit51 OR dir bit to carry 2 1 (3) 2 1 (3)
CY,bit OR dir bit to carry 4 3 (3) 3 2 (3)
ORL/
CY,/bit51 OR complemented dir bit to carry 2 1 (3) 2 1 (3)
CY,/bit OR complemented dir bit to carry 4 3 (3) 3 2 (3)
MOV
CY,bit51 Move dir bit to carry 2 1 (3) 2 1 (3)
CY,bit Move dir bit to carry 4 3 (3) 3 2 (3)
bit51,CY Move carry to dir bit 2 2 (2) 2 2 (2)
bit,CY Move carry to dir bit 4 4 (2) 3 3 (2)
NOTES:
1. A shaded cell denotes an instruction in the MCS
®
51 architecture.
2. If this instruction addresses an I/O port (P
x , x = 0–3), add 2 to the number of states.
3. If this instruction addresses an I/O port (P
x , x = 0–3), add 1 to the number of states.
