Appendix B: Compatible Intel® Server Chassis Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS
Revision 1.8
Intel order number E39529-013
148
S5520HC S5500HCV Chassis SKU Heatsink Includes
Intel
®
Thermal Solution
STS100C (w/ fan, Active
mode)
Intel
®
Thermal Solution
STS100A (Active)
FXXRGTHSINK
(Passive Tower Heatsink)
Chassis
Boxed
Product Code
BXSTS100C BXSTS100A FXXRGTHSINK
Note: Must install active processor heatsink with the airflow direction as shown in the following figure when installing in a compatible
Intel
®
Server Chassis.
