Functional Architecture Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS
Revision 1.8
Intel order number E39529-013
46
Table 12. Intel
®
SAS Entry RAID Module AXX4SASMOD Storage Mode
SW RAID = Intel
®
Embedded Server RAID Technology II (ESRTII)
IT/IR RAID = IT/IR RAID, Entry Hardware RAID
Storage
Mode*
Description
RAID Types and Levels
Supported
Driver
RAID Management
Software
RAID
Software
User’s Guide
Compatible
Backplane
IT/IR RAID
4 SAS Ports
Up to 10 SAS
or SATA drives
via expander
backplanes
Native SAS pass
through mode without
RAID function.
Entry Hardware
RAID.
RAID 1 (IM mode)
RAID 10/10E (IME
mode)
RAID 0 (IS Mode)
SAS MPT
driver (Fully
open-source
driver)
Broad OS
support.
Intel
®
RAID Web
Console 2
IT/IR RAID
Software
User’s
Guide
AXX6DRV3GR
AXX4DRV3GR
AXX6DRV3GEXP
AXX4DRV3GEXP
SW RAID
4 SAS Ports
Up to 8 SAS or
SATA drives
via expander
backplanes
SW RAID 0/1/10
standard
SW RAID 5 with
optional
AXXRAKSW5
ESRTII Driver
Microsoft
Windows* and
selected
Linux*
Versions only
Intel
®
RAID Web
Console 2
Intel
®
RAID
Software
User’s
Guide
*Select in BIOS Setup: “Configure Intel
®
SAS Entry RAID” Option on Advanced | Mass Storage Controller
Configuration Screen
3.6.1.1 IT/IR RAID Mode
Supports entry hardware RAID 0, RAID 1, and RAID 1E and native SAS pass-through mode.
3.6.1.2 Intel
®
ESRTII Mode
The Intel
®
Embedded Server RAID Technology II (Intel
®
ESRTII) feature provides RAID modes
0, 1, and 10. If RAID 5 is needed with Intel
®
ESRTII, you must install the optional Intel
®
RAID
Activation Key AXXRAKSW5 accessory. This activation key is placed on the SAS Software
RAID 5 connector located on the Intel
®
SAS Entry RAID Module AXX4SASMOD. For installation
instructions, see the documentation included with the SAS Module AXX4SASMOD and the
activation key.
When Intel
®
Embedded Server RAID Technology II is enabled with the SAS Module
AXX4SASMOD, enclosure management is provided through the SAS_SGPIO or SES connector
on the SAS Module AXX4SASMOD when a cable is attached between this connector and the
backplane or I
2
C interface.
