Overview Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS
Revision 1.8
Intel order number E39529-013
2
2. Overview
The Intel
®
Server Boards S5520HC, S5500HCV and S5520HCT are monolithic printed circuit
boards (PCBs) with features designed to support the pedestal server markets.
2.1 Intel
®
Server Boards S5520HC, S5500HCV and S5520HCT Feature Set
Feature Description
Processors
• Support for one or two Intel
®
Xeon
®
Processor(s) 5500 series up to 95W Thermal Design
Power
• Support for one or two Intel
®
Xeon
®
Processor(s) 5600 series up to 130W Thermal Design
Power
• 4.8 GT/s, 5.86 GT/s, and 6.4 GT/s Intel
®
QuickPath Interconnect (Intel
®
QPI)
• FC-LGA 1366 Socket B
 Enterprise Voltage Regulator-Down (EVRD) 11.1
Memory
• Six memory channels (three channels for each processor socket)
 Channels A, B, C, D, E, and F
• Support for 800/1066/1333 MT/s ECC Registered DDR3 Memory (RDIMM), ECC
Unbuffered DDR3 memory ((UDIMM)
• No support for mixing of RDIMMs and UDIMMs
• Intel
®
Server Board S5520HC/S5520HCT:
 12 DIMM slots
 Two DIMM slots per channel
• Intel
®
Server Board S5500HCV
 Nine DIMM slots
 Two DIMM slots on Channels A, B, and C
 One DIMM slot on Channels D, E, and F
Chipset
• Intel
®
Server Board S5520HC/S5520HCT:
 Intel
®
5520 Chipset
 Intel
®
82801JIR I/O Controller Hub (ICH10R)
• Intel
®
Server Board S5500HCV:
 Intel
®
5500 Chipset
 Intel
®
82801JIR I/O Controller Hub (ICH10R)
Cooling Fan Support Support for
• Two processor fans (4-pin headers)
• Four front system fans (6-pin headers)
• One rear system fans (4-pin header)
• 3-pin fans are compatible with all fan headers
