Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS Overview
Revision 1.8
Intel order number E39529-013
3
Feature Description
Add-in Card Slots
• Intel
Server Board S5520HC/S5520HCT: Six expansion slots
One full-length/full-height PCI Express* Gen2 slot (x16 Mechanically, x8 Electrically)
Three full-length/full-height PCI Express* Gen2 x8 slots
One full-length/full-height PCI Express* Gen1 slot (x8 Mechanically, x4 Electrically)
shared with SAS Module slot*.
One 32-bit/33 MHz PCI slot, keying for 5-V and Universal PCI add-in card
• Intel
®
Server Board S5500HCV: Five expansion slots
One full-length/full-height PCI Express* Gen2 slot (x16 Mechanically, x4 Electrically)
Two full-length/full-height PCI Express* Express* Gen2 x8 slots
One full-length/full-height PCI Express* Gen1 slot (x8 Mechanically, x4 Electrically)
shared with SAS Module slot*.
One 32-bit/33 MHz PCI slot, keying for 5-volt and Universal PCI add-in card
Hard Drive and
Optical Drive
Support
• Optical devices are supported
• Six SATA connectors at 1.5 Gbps and 3 Gbps
• Four SAS connectors at 3 Gbps through optional Intel
®
SAS Entry RAID Module
AXX4SASMOD
RAID Support
• Intel
Embedded Server RAID Technology II through onboard SATA connectors provides
SATA RAID 0, 1, and 10 with optional RAID 5 support provided by the Intel
®
RAID
Activation Key AXXRAKSW5
• Intel
®
Embedded Server RAID Technology II through optional Intel
®
SAS Entry RAID
Module AXX4SASMOD provides SAS RAID 0, 1, and 10 with optional RAID 5 support
provided by the Intel
®
RAID Activation Key AXXRAKSW5
• IT/IR RAID through optional Intel
®
SAS Entry RAID Module AXX4SASMOD provides entry-
level hardware RAID 0, 1, 10/10E, and native SAS pass through mode
• 4 ports full featured SAS/SATA hardware RAID through optional Intel
®
Integrated RAID
Module SROMBSASMR (AXXROMBSASMR), provides RAID 0, 1, 5, 6 and striping
capability for spans 10, 50, 60.
USB Drive Support
• One internal type A USB port with USB 2.0 support that supports a peripheral, such as a
floppy drive
• One internal low-profile USB port for USB Solid State Drive
I/O control support
• External connections:
DB9 serial port A connection
One DH 10 serial port connector (optional)
Two RJ-45 NIC connectors for 10/100/1000 Mb connections: Dual GbE through the
Intel
®
82575EB Network Connection.
Four USB 2.0 ports at the back of the board
• Internal connections:
Two 9-pin USB headers, each supports two USB 2.0 ports
One DH10 serial port B header
Six SATA connectors at 1.5 Gbps and 3 Gbps
Four SAS connectors at 3 Gbps (optional)
One SSI-compliant 24-pin front control panel header
Video Support
• ServerEngines* LLC Pilot II* with 64 MB DDR2 memory, 8 MB allocated to graphics
Integrated 2D video controller
Dual monitor video mode is supported
LAN
• Two Gigabit through Intel
82575EB PHYs with Intel
I/O Acceleration Technology 2
support
Security**
• Trusted Platform Module
