Overview Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS
Revision 1.8
Intel order number E39529-013
4
Feature Description
Server Management
• Onboard ServerEngines* LLC Pilot II* Controller
Integrated Baseboard Management Controller (Integrated BMC), IPMI 2.0 compliant
Integrated Super I/O on LPC interface
• Support for Intel
®
Remote Management Module 3
• Intel
®
Light-Guided Diagnostics on field replaceable units
• Support for Intel
®
System Management Software 3.1 and beyond
• Support for Intel
®
Intelligent Power Node Manager (Need PMBus-compliant power supply)
BIOS Flash
• Winbond* W25X64
Form Factor
• SSI EEB (12”x13”)
Compatible Intel
Server Chassis
• Intel
Server Chassis SC5650DP
• Intel
®
Server Chassis SC5650BRP (PMBus-compliant Power Supply)
• Intel
®
Server Chassis SC5600Base
• Intel
®
Server Chassis SC5600BRP (PMBus-compliant Power Supply)
• Intel
®
Server Chassis SC5600LX (PMBus-compliant Power Supply)
* The PCI Express* Gen 1 slot (x8 Mechanically, x4 Electrically) is not available when the SAS module slot is in use
and vice versa.
**The Trusted Platform Module is only availabe in S5520HCT
