Intel Desktop Board DG965MQ Product Guide
12
Table 2. Desktop Board DG965MQ Components
Label Description
A Front panel audio header
B Back panel connectors
C Hi-speed USB 2.0 headers
D Serial ATA connectors
E PCI Express x16 connector
F PCI Express x1 connector
G PCI bus connector 1
H PCI bus connector 2
I IEEE 1394a header
J Diskette drive connector
K IDE connector
L Serial port header
M Parallel port header
N Front panel header
O Front chassis fan header (3-pin)
P Alternate front panel power LED header
Q Speaker
R Chassis intrusion header
S HD Audio Link header
T Processor socket
U 12 V processor core voltage connector (2 x 2 pin )
V Processor fan header (4-pin)
W DIMM 1, Channel A and B sockets
X DIMM 0, Channel A and B sockets
Y Rear chassis fan header (3-pin)
Z Battery
AA Main power connector (2 x 12 pin)
BB BIOS configuration jumper block
Related Links:
Go to the following links for more information about:
• Desktop Board DG965MQ
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Supported processors
http://www.intel.com/go/findCPU
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd
