Intel Deskto
p Board DG965MQ Pro
duct Guide
56
Setting the BIOS Configuration Jumper
NOTE
Always turn off the power and unplug the
power cord from the computer be
fore
moving the jumper.
Moving the jumper wi
th the power on may result in unreliable
computer
operatio
n.
Figure 30 shows the location of
the desktop board’s BIOS configuratio
n jumper block.
Figure
30. Loc
ation o
f the BIO
S Config
urat
ion Jumper
Block
55
57
