Intel Deskto
p Board DG965MQ Pro
duct Guide
68
Recovering the BIOS
It is unlikely that anything will interr
upt the BIOS update; ho
wever, if an inter
ruption
occurs, the
BIOS could be damaged. Due to BIOS size and recovery
requirements, a
CD-R with the .BIO file in the roo
t directory will be required.
For more information
about recover
ing the BIOS for desktop board DG965MQ, go to:
http://support.
intel.com/suppo
rt/motherboar
ds/desktop/
67
