Intel Desktop Board DH61AG Technical Product Specification
14
Table 2. Feature Summary (continued)
Peripheral
Interfaces
• Two USB 3.0 ports, via an NEC D720200 controller, implemented through two
back panel connectors (blue)
• Ten USB 2.0 ports:
― Four ports implemented through two dual-port internal headers (black)
― One single-port internal header (black)
― Two high-current/fast-charging ports implemented through stacked back
panel connectors (yellow)
― One port implemented in the PCI Express Half–Mini Card slot
― Two ports implemented in the PCI Express Full-Mini Card slot
• Four SATA ports:
― Two internal SATA connectors (black)
― One back panel eSATA connector (red)
― One internal mSATA port (PCI Express Full-Mini Card slot)
Expansion
Capabilities
• One PCI Express 2.0 x4 add-in card connector
• One PCI Express Half-Mini Card slot
• One PCI Express Full-/Half-Mini Card slot
BIOS
• Intel
®
BIOS resident in the Serial Peripheral Interface (SPI) Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and System Management BIOS (SMBIOS)
LAN Support
Gigabit (10/100/1000 Mbits/s) LAN subsystem using the Intel
®
82579V Gigabit
Ethernet Controller
Legacy I/O Control Nuvoton W83677HG-i I/O controller for CIR and hardware management support
Hardware Monitor
Subsystem
• Hardware monitoring through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Two fan headers
• Two fan sense inputs used to monitor fan activity
• Fan speed control

Intel DH61AG Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16.6 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Product family	Desktop board
Product series	Intel desktop board with Intel H61 Express
Processor socket	LGA 1155 (Socket H2)
Product codename	-
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum internal memory supported by processor	16 GB
USB 2.0 connectors	3
S/PDIF out connector	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	Nettop
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
LAN controller	Intel® 82579V
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	3.0b
BIOS memory size	32 Mbit
Status	Discontinued
Form factor	Thin Mini-ITX
Last change	63903513
Born on date	Q2'11
Product name	Intel Desktop Board DH61AG
USB ports quantity	12
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Audio channels	8.2
Graphics output	LVDS eDP HDMI DVI-I
Motherboard ARK ID	54875
Discrete graphics card model	None
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Harmonized System (HS) code	8473301180

Weight and Dimensions

Width	172 mm
